SEC-200
1 / 3
Carton Sealer
Semi-automatic Carton Sealer Machine
SilverSeal ref. SEC-195
The semi-automatic carton sealer machine draws 180 W. It arrives wired for AC 220/50 110/60. Plan for 80 kg net on the floor.
- Voltage (V/Hz)
- AC 220/50 110/60
- Power (W)
- 180
- Net weight (kg)
- 80
Overview
Description: series semiautomatic carton sealer is mainly used to seal cartons, which can operate alone and can also be equipped into production line. Application: series semiautomatic carton sealer is suitable for circumstance where the size of cartons does not change frequently, which especially fits for continuous sealing of cartons in the same size. The machine is used in the fields of domestic electrical appliance, foodstuffs, general merchandise, pharma and process industries industries. Features: 1. Be suitable for 1# to 12# postal cartons 2. It's convenient to change the tape 3. 5cm is reserved for the tape head 4. High production efficiency 5. Dual motor drive 6. Simple operation.
Technical specifications
| Model | SEC-195 |
|---|---|
| Voltage (V/Hz) | AC 220/50 110/60 |
| Power (W) | 180 |
| Tape width (mm) | BOPP, PVCadhesive tape, water-free adhesive tape |
| Table height (mm) | 700 |
| Dimensions L×W×H (mm) | 620(with bracket1305)x700 x (1220-1580) |
| Net weight (kg) | 80 |
| Conveyor load (kg) | 20 |
| Gr. Wt. (kg) | 128 |
| Height（CM） | 110 |
| Length（CM） | 100 |
| Net. Wt. (kg) | 88 |
| Pack size (mm) | ∞x300 x 400 |
| Package Type | W/C |
| Pcs/CTN (pc) | 1 |
| Single piece volume (CBM) | 1.078 |
| Taping Speed (m/min) | 20 |
| Width（CM） | 98 |
