Band Sealer
Band Sealer
SilverSeal ref. SEB-220
The band sealer runs at 0-24 m/min, seals a 10 mm band, draws 400x2 W. It sits mid-range among the 6 band sealers we list (152 kg), between the SEB-455 and SEB-120 units. It arrives wired for AC 220/50 110/60, coding by ink-jet coding. Plan for a 1730x660x1030 mm footprint on the floor.
- Voltage (V/Hz)
- AC 220/50 110/60
- Sealing power (W)
- 400x2
- Speed (m/min)
- 0-24
- Sealing width (mm)
- 10
- Dimensions L×W×H (mm)
- 1730x660x1030
- Net weight (kg)
- 152
Overview
Application Vertical Sealing Machine is suitable for sealing medium and large bags that require air sucking or flushing. It integrates air sucking, flushing, sealing, and ink-jet coding. It adopts touch screen for the simple operation, multiple functions, and perfect sealing effect. Adopt Horizontal Movable Sucking Air Nozzle √Compared to other types of air suction band sealer or those use swinging air nozzles, it has higher vacuum degree. √Compared to traditional vacuum machines, it has higher work efficiency. Benefit Of Ink-jet Band Sealer One Machine For Three Use Meet different needs: Air Sucking/Gas Flushing/Integrated Suction and Inflation. 5 Customizable Coding Options: Inkjet | Solid Ink | Ribbon | CO₂ Laser Marking | UV Laser Marking High Power and Strong Suction Effect：Reduce air inside the bag, shrink the bag size, and avoid bloating during transportation. Great Sealing Effect：Quick and precise temperature control, no wrinkling or cracking of sealing effect. Adjustable Machine Head: 15° tilted angle of conveyor table, it can be applied to materials containing liquid and prevent leakage of materials during the packaging process. Clear Coding：Accurate coding, efficient and fast drying, free editing and printing ofcontent. Diverse Coding Content：Printable text, date, symbol, logo image,QR code,barcode and other content.
Technical specifications
| Model | SEB-220 |
|---|---|
| Voltage (V/Hz) | AC 220/50 110/60 |
| Sealing power (W) | 400x2 |
| Motor power (W) | 180 |
| Speed (m/min) | 0-24 |
| Sealing width (mm) | 10 |
| Temperature range (°C) | 0-300（Stepless adjustable） |
| Air supply (MPa) | 0.5（Equipped by user） |
| Printing type | Ink-jet coding |
| Dimensions L×W×H (mm) | 1730x660x1030 |
| Net weight (kg) | 152 |
| Bag size (mm) | 80-400 |
| Conveyor Size（LxW） (mm) | 1730x300 |
| Conveyor load (kg) | 15 |
| Diameter of Air Supply Pipe（mm） | 12 |
| Diameter of Charging Air Source Connecting Pipe（mm） | 8 |
| Max distance from sealing center to bag mouth（mm） | 35 |
| Min distance from sealing center to material（mm） | 55 |
| Sealing centre distance (mm) | 0-40 |
