Band Sealer
SilverSeal ref. SEB-215
The band sealer runs at 0-10 m/min, seals a 10 mm band. It sits mid-range among the 8 band sealers we list (0-10 m/min), between the SEB-120 and SEB-455 units. It arrives wired for AC 220/50 110/60, fed from a 0.5 MPa air line, holding 0-300 °C.
- Voltage (V/Hz)
- AC 220/50 110/60
- Sealing power (W)
- 400W*2
- Speed (m/min)
- 0-10
- Sealing width (mm)
- 10
Overview
Product Description is suitable for sealing medium and large bags that require air sucking or flushing. It integrates air sucking,flushing, sealing, and ink-jet coding. It adopts touch screen for the simple operation, multiple functions, and perfect sealing effect. Product Introduction This air sucking and gas flushing sealing machine is suitable for sealing and bagging plastic films. It can be used for vacuum packaging, gas packaging or vacuum-filled packaging forlarge solid particles,foods that are not easy to producefine powder, fruits, seeds, aromatics, pharma, process industries products, electronic products, precision instruments, rare and precious metals, etc., and various inert gases can be filled in. The volume of the packaged products is reduced for easy storage,and it canalso prevent oxidation,mildew,nsect infestation,corruption,moisture toacertain extent, and can preserve quality and freshness to extend the storage period of the items. The coding control operation system uses the Linux operating system, which is free and open source, is widely used around the world, has good portability, and the system has strong stability and scalability, and can run stably for a long time. Customers can adjust the size and length of the printing font according to their own needs, and the printing content is rich. The vertical band sealer machine has a built-in sealing counting function and can be widely used in food, pharma, process industries, daily necessities, agriculture and other industries. It is the best sealing equipment for batch product packaging in factories and stores. Features This continuous band sealer machine adopts synchronous belt clamping bag feeding, with uniform clamping pressure and good sealing effect.The air nozzle extends into the bag to work, forming an independent working space. This machine has the characteristics of high continuous sealing effciency, reliable sealing quality, reasonable structure and convenient operation. The inflation pressure is adjustable, which can be applied to packaging bags of different sizes, and the filling gas can be selected by the customer. This vacuum and Gas Flushing Sealer machine has multiple functions such as vacuuming (inflating), sealing, printing, etc., which can meet customers' needs for one machine with multiple functions. There are multiple gas adjustment modes to choose from, including separate exhaust, separate inflation, and exhaust first and then inflation. Touch screen control, simple interface, easy operation, you can freely adjust the value according to your needs.Vacuum pressure gauge display, you can directly observe the pressure data, clear and intuitive. High-precision linear guide rails are used for load-bearing, and the operation is smooth to ensure stability without shaking.The cylinder movement has a simple mechanism, stable structure and quick action. This sealing machine uses intelligent inkjet equipment. Customers can adjust the font size and length of the printing according to their own needs. The printing content is rich and can print text, date, symbol, LOGO image, QR code, barcode, etc. One-click language switching, more than 20 languages are supported (including corresponding language input method), and any language customization is supported.
Technical specifications
| Model | SEB-215 |
|---|---|
| Voltage (V/Hz) | AC 220/50 110/60 |
| Sealing power (W) | 400W*2 |
| Motor power (W) | 200 |
| Speed (m/min) | 0-10 |
| Sealing width (mm) | 10 |
| Temperature range (°C) | 0-300 |
| Air supply (MPa) | 0.5 |
| Printing type | Ink-jet coding |
| Bag size (mm) | 80-400 |
| Conveyor Size (L*W) (mm) | 1780*250 |
| Conveyor load (kg) | 15 |
| Diameter of Air Supply Pipe (mm) | 12 |
| Diameter of Charging Air Source Connecting Pipe (mm) | 8 |
| External Size (L*W*H) (mm) | 1780*650*1565 |
| Min.Distance from Sealing Center to the Material (mm) | 40 |
| Sealing centre distance (mm) | 50 |
