Heavy Duty Plastic Bag Packaging Machine
Heavy Duty Plastic Bag Packaging Machine
SilverSeal ref. SEA-260
It sits mid-range among the 5 heavy duty plastic bag packaging machines we list (200 kg), between the SEA-275 and SEA-255 units. It arrives wired for AC 380/50, fed from a 0.6 MPa air line. Plan for a 1120×1313×2780 mm footprint on the floor.
- Voltage (V/Hz)
- AC 380/50
- Speed (m/min)
- 9(Customized 8-16)
- Dimensions L×W×H (mm)
- 1120×1313×2780
- Net weight (kg)
- 200
Models in this series
3 sizes share this build. The table shows only what changes between them.
| Reference | Model | Motor power (W) | Speed (m/min) | Dimensions L×W×H (mm) | Net weight (kg) | Gross Power （ KW) | Height Space Request of BagTop | Needle Mode | Paper Tape Width (mm) | Sewing Machine Model | Folding Width (mm) | Height Space Request of BagTop（mm） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SEA-260 | SEA-260 | 0.18 | 9(Customized 8-16) | 1120×1313×2780 | 200 | 1 | 200-250 | 80800×250# | 55 | 7(Optional 、-1、 ) | — | — |
| SEA-265 | SEA-265 | — | 9(Customized 8-16) | 1120×1135×2750 | 150 | 0.6 | 200-250 | 80800×250# | 65 | 7(Optional 、-1、 ) | — | — |
| SEA-270 | SEA-270 | 0.18 | 9(Customize upper limit 11) | 1250×1119×2750 | 200 | 0.6 | — | 80800X250# | — | 6A(Optional 、-1、) | 55-60 | 200-250 |
Technical specifications
| Model | SEA-260 |
|---|---|
| Voltage (V/Hz) | AC 380/50 |
| Motor power (W) | 0.18 |
| Speed (m/min) | 9(Customized 8-16) |
| Air supply (MPa) | 0.6 |
| Dimensions L×W×H (mm) | 1120×1313×2780 |
| Net weight (kg) | 200 |
| Gross Power （ KW) | 1 |
| Height Space Request of BagTop | 200-250 |
| Needle Mode | 80800×250# |
| Paper Tape Width (mm) | 55 |
| Sealing centre distance (mm) | 700-1400 |
| Sewing Machine Model | 7(Optional 、-1、 ) |
| Sewing Machine Specification | 20S/6 、 20S/9 fiber thread |
