Heavy Duty Plastic Bag Packaging Machine
Heavy Duty Plastic Bag Packaging Machine
SilverSeal ref. SEA-245
It arrives wired for AC 380/50, fed from a 0.6 MPa air line, holding 0-400 °C. Set up with motor power 0.37, sealing centre distance 750-1450, the minimum distance between the top of bag 180.
- Voltage (V/Hz)
- AC 380/50
- Speed (m/min)
- 8.5(Customized upper limit 11)
Models in this series
2 sizes share this build. The table shows only what changes between them.
| Reference | Model | Application | Sealing centre distance (mm) |
|---|---|---|---|
| SEA-245 | SEA-245 | Multi-layer paper bag 、 paper-PE compound bag and 2 in 1 or 3 in 1 bag etc. | 750-1450 |
| SEA-250 | SEA-250 | Multi-layer paper bag 、 paper-PE compound bag .2 in 1 or 3 in 1 bag, AL-PE inner liner bag or PE bag, etc. | 800-1400 |
Technical specifications
| Model | SEA-245 |
|---|---|
| Voltage (V/Hz) | AC 380/50 |
| Motor power (W) | 0.37 |
| Speed (m/min) | 8.5(Customized upper limit 11) |
| Temperature range (°C) | 0-400 |
| Air supply (MPa) | 0.6 |
| Application | Multi-layer paper bag 、 paper-PE compound bag and 2 in 1 or 3 in 1 bag etc. |
| Sealing centre distance (mm) | 750-1450 |
| The minimum distance between the top of bag (mm) | 180 |
