Solid-ink Coding Machine
Solid-ink Coding Machine
SilverSeal ref. SEM-155
The solid-ink coding machine draws 180 W. It arrives wired for AC 220/50 110/60. Plan for a 440×345×260 mm footprint and 23 kg net on the floor.
- Voltage (V/Hz)
- AC 220/50 110/60
- Power (W)
- 180
- Dimensions L×W×H (mm)
- 440×345×260
- Net weight (kg)
- 23
Overview
Solid-Ink Coding Machine print expiry date code, lot number, batch number, etc. on paper box, card and label. The machine will automatically working when a stack of labels is putted in the feeding box It is widely used in pharmacy, cosmetic industries. Adopt photoelectric mechanism technology, featuring automatic temperature control, auto counting & adjustable print position. Adopt solid-ink coding with selectable color, featuring legible printing, instant printing-instant drying and strong adhesion. There're types in size of 1.5mm, 2mm, 2.5mm & 3mm for selection. Fit for printing codes on paper, thin paper board, plastic film and aluminum foil. The machine is automatic, with high speed & high efficiency up to 300pcs/minute.
Models in this series
2 sizes share this build. The table shows only what changes between them.
| Reference | Model |
|---|---|
| SEM-155 | SEM-155 |
| SEM-160 | SEM-160 |
Technical specifications
| Model | SEM-155 |
|---|---|
| Voltage (V/Hz) | AC 220/50 110/60 |
| Power (W) | 180 |
| Dimensions L×W×H (mm) | 440×345×260 |
| Net weight (kg) | 23 |
| Max. Printing Line | T type (10.5PT):11 lines(Max.10 characters/line) R type (10.5PT):8 lines(Max.11 characters/line) |
| Object Size (mm) | L:50-500 W:30-190 |
| Printing Size (mm) | Single side 60-250 |
| Printing Speed (pcs (/min) | ≤300 |
| Solid Ink Roller (mm) | 35×32 |
| Type Size (mm) | 2.5×1.5(8PT) 2×2.5(9PT) 3×2(10.5PT) 5×2.5(18PT) |
