SEK-250
1 / 7
Side Sealing and Shrinking Packaging Machine
Side Sealing and Shrinking Packaging Machine
SilverSeal ref. SEK-240
The side sealing and shrinking packaging machine runs at 0~25 m/min, works a 1500×500×300 mm chamber. It sits mid-range among the 3 side sealing and shrinking packaging machines we list (800 kg), between the SEK-250 and SEK-255 units. Plan for a 2040×1480×1350 mm footprint on the floor.
- Power (W)
- 3
- Speed (m/min)
- 0~25
- Capacity
- 0-40
- Dimensions L×W×H (mm)
- 2040×1480×1350
- Net weight (kg)
- 800
Overview
High-Speed Side Sealing Machine is available with centerfold film to seal three sides, it adopts automatically or manually feed type, it suitable for fully automatic shrink wrapping. High-Speed ShrinkTunnel is suitable for fully automatic shrink wrapping with high speed.
- High-Speed Side Sealing Machine
- Continuous side sealing without product length limit
- High packing speed can reach 40-60 pcs/minutes
- Sealing system controlled by servo motor ensures accurate position and perfect sealing
- Transparent window function can show shrinking process inside
- Inner insulate shell, temperature uniformity
Models in this series
2 sizes share this build. The table shows only what changes between them.
| Reference | Model | Voltage (V/Hz) | Power (W) | Speed (m/min) | Capacity | Sealing length (mm) | Tunnel L×W×H (mm) | Dimensions L×W×H (mm) | Net weight (kg) | Compressed Air (kg/cm3) | Pack size (mm) | Conveyor load (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SEK-240 | SEK-240 | 3 Phase 380/50 or 3 Phase 220/60 | 3 | 0~25 | 0-40 | 450 | 1500×500×300 | 2040×1480×1350 | 800 | 44355 | W+H≤450，W<350 Length unlimited | — |
| SEK-245 | SEK-245 | 1 Phase 220/50 | 1.6 | 0~10 | 0-30 | 52 | 1000×450×250 | 1930×1000×1600 | 500 | 5-8 | W+H≤ 450,W≤350,H≤150，Length unlimited | 10 |
Technical specifications
| Model | SEK-240 |
|---|---|
| Voltage (V/Hz) | 3 Phase 380/50 or 3 Phase 220/60 |
| Power (W) | 3 |
| Speed (m/min) | 0~25 |
| Capacity | 0-40 |
| Sealing length (mm) | 450 |
| Tunnel L×W×H (mm) | 1500×500×300 |
| Dimensions L×W×H (mm) | 2040×1480×1350 |
| Net weight (kg) | 800 |
| Compressed Air (kg/cm3) | 44355 |
| Max. Packing Height (mm) | 150 |
| Pack size (mm) | W+H≤450，W<350 Length unlimited |
