Automatic Side Sealing Machine
Automatic Side Sealing Machine
SilverSeal ref. SEK-100
The automatic side sealing machine runs at 0~25 m/min, works a 1500×500×300 mm chamber. It arrives wired for 220V 50/60HZ, fed from a 6-8 MPa air line. Plan for a 1790×830×1600 mm footprint and 400 kg net on the floor.
- Voltage (V/Hz)
- 220V 50/60HZ
- Power (W)
- 1.8
- Speed (m/min)
- 0~25
- Capacity
- 0-30
- Dimensions L×W×H (mm)
- 1790×830×1600
- Net weight (kg)
- 400
Overview
Fully Electric Heat Shrink Packaging Machine is your reliable choice! Description: This shrink wrapping machine is driven by a servo motor, which is more convenient to operate without air source and effectively saves costs; at the same time, the cutter is also driven by a servo motor, and the action is precise and stable.
Technical specifications
| Model | SEK-100 |
|---|---|
| Voltage (V/Hz) | 220V 50/60HZ |
| Power (W) | 1.8 |
| Speed (m/min) | 0~25 |
| Capacity | 0-30 |
| Tunnel L×W×H (mm) | 1500×500×300 |
| Air supply (MPa) | 6-8 |
| Dimensions L×W×H (mm) | 1790×830×1600 |
| Net weight (kg) | 400 |
| Load (kg) | 0-20 |
| Max. Sealing & Cutting Size (L×H) (mm) | 500×400 |
| Pack size (mm) | L≤400，W≤350，H≤130，W+H≤480，L+H≤500 |
