Induction Sealer
Induction Sealer
SilverSeal ref. SEB-300
The induction sealer draws 500W. It arrives wired for AC 220/50 110/60. Plan for a 340×290×150mm footprint and 5Kg net on the floor.
- Voltage (V/Hz)
- AC 220/50 110/60
- Sealing power (W)
- 500W
- Dimensions L×W×H (mm)
- 340×290×150mm
- Net weight (kg)
- 5Kg
Overview
electromagnetic induction capper is mainly applicable to capping operation of non-metal bottleneck (i.e. plastics, glass) which features of flat threaded cap, but not applicable to capping operation of metal & non-threaded pressing cap, cap with diameter < φ20mm or > φ100mm and active handle, high cap with over 3 mm spacing between cap surface & bottleneck after screwed in, Especially, it is suitable for the customers who carrying out continuous capping operation for large output and lot.
Models in this series
4 sizes share this build. The table shows only what changes between them.
| Reference | Model | Sealing power (W) | Seal diameter |
|---|---|---|---|
| SEB-300 | SEB-300 | 500W | φ20-φ100 |
| SEB-305 | SEB-305 | 500W | φ15-φ35 |
| SEB-310 | SEB-310 | 600W | φ60-φ130 |
| SEB-315 | SEB-315 | 600W | φ20-φ60 |
Technical specifications
| Model | SEB-300 |
|---|---|
| Voltage (V/Hz) | AC 220/50 110/60 |
| Sealing power (W) | 500W |
| Dimensions L×W×H (mm) | 340×290×150mm |
| Net weight (kg) | 5Kg |
| Seal diameter | φ20-φ100 |
