Tray Vacuum Packaging Machine

Tray Vacuum Packaging Machine

SilverSeal ref. SES-295

A tray vacuum packaging machine from the SilverSeal vacuum packaging range. Plan for a 2800×950×1620 mm footprint on the floor. Set up with sealing power 2, ultimate vacuum 1, cooling type Water-cooling.

Voltage (V/Hz)
AC 380/50((three phases)
Power (W)
4.43
Sealing power (W)
2
Chamber L×W×H (mm)
450×(200-400)
Dimensions L×W×H (mm)
2800×950×1620
Net weight (kg)
Approx.670
Request a quote

Overview

Tray Sealer It applicable to sealing kinds of PP or PE tray, could automatically finish the process of vacuuming, gas flushing, sealing and film cutting and so on. It could do continuous packaging for higher efficiency. Tray Vacuum Gas-flushing Packaging Machine replaces the air in the bag by protective mixture gas; inhibit the growth of most microorganisms which may make the food prone to spoiling and trichinosis; decrease the respiration of the active food (like fruit) so as to prolong the fresh time. It is applicable to industrialized package of food or distribution of supermarkets. The mould could be designed to meet the customers' tray size. It adopts removable moulds which enable single machine to meet different sizes of moulds. A Tray Sealer Feature Function: Ensure the freshness of food, prevent bacterial growth, and extend the shelf life of food Application industries: food industry, seafood industry, frozen food industry, pre-prepared food industry, catering industry, supermarkets and personal household use, such as various fresh product trays in supermarkets, fast food trays, student lunch boxes, etc. Application: fresh meat, fruits and vegetables, seafood, hardware tools, electrical and electronic components, toys, crafts, small pharma devices, etc.

Models in this series

2 sizes share this build. The table shows only what changes between them.

ReferenceModelVoltage (V/Hz)Power (W)Sealing power (W)CapacityChamber L×W×H (mm)Dimensions L×W×H (mm)Net weight (kg)
SES-295SES-295AC 380/50((three phases)4.43210-12 for only sealing ; 2-3 for vacuum450×(200-400)2800×950×1620Approx.670
SES-300SES-300AC 380/50 ( three phases )3680200010-12 for only sealing ; 3-5 for vacuum, gas-flushing and sealing400× ( 200-400 )1238×1500×1545Approx.650

Technical specifications

ModelSES-295
Voltage (V/Hz)AC 380/50((three phases)
Power (W)4.43
Sealing power (W)2
Capacity10-12 for only sealing ; 2-3 for vacuum
Chamber L×W×H (mm)450×(200-400)
Ultimate vacuum (kPa)1
Dimensions L×W×H (mm)2800×950×1620
Net weight (kg)Approx.670
Cooling typeWater-cooling
Flushing gasN2 or N2+CO2
Pump capacity (m 3 /h)63
