Automatic Horizontal Packaging Machine
Automatic Horizontal Packaging Machine
SilverSeal ref. SEH-100
The automatic horizontal packaging machine draws 2400 W. It arrives wired for AC 220/50 220/60. Plan for a 3770×670×1450 mm footprint and 600 kg net on the floor.
- Voltage (V/Hz)
- AC 220/50 220/60
- Power (W)
- 2400
- Dimensions L×W×H (mm)
- 3770×670×1450
- Net weight (kg)
- 600
Models in this series
7 sizes share this build. The table shows only what changes between them.
| Reference | Model | Voltage (V/Hz) | Power (W) | Dimensions L×W×H (mm) | Net weight (kg) | Film (mm) | Sealing power (W) | Motor power (W) | Output | Temperature range (°C) | Air supply (MPa) | Max. Size of Packing Object (W×H) (mm) | Number of Printing |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SEH-100 | SEH-100 | AC 220/50 220/60 | 2400 | 3770×670×1450 | 600 | Max.250 | — | — | — | — | — | — | — |
| SEH-105 | SEH-100 | AC 220/50 220/60 | 2400 | 3770×670×1450 | 600 | Max.250 | — | — | — | — | — | — | — |
| SEH-115 | SEH-100 | AC 220/50 220/60 | 2400 | 3770×670×1450 | 600 | Max.250 | — | — | — | — | — | — | — |
| SEH-120 | SEH-100 | AC 220/50 220/60 | 2400 | 3770×670×1450 | 600 | Max.250 | — | — | — | — | — | — | — |
| SEH-125 | SEH-100 | AC 220/50 220/60 | 2400 | 3770×670×1450 | 600 | Max.250 | — | — | — | — | — | — | — |
| SEH-110 | SEH-100 | AC 220/50 220/60 | 2400 | 3770×670×1450 | 600 | Max.250 | — | — | — | — | — | — | — |
| SEH-130 | SEH-130 | 380/50 220/60 (3PH) | — | 6619×1863×985 | 750 | — | 5000 | 3500 | 20 | 0~300 | 0.6 | 520×280 | 10 |
Technical specifications
| Model | SEH-100 |
|---|---|
| Voltage (V/Hz) | AC 220/50 220/60 |
| Power (W) | 2400 |
| Dimensions L×W×H (mm) | 3770×670×1450 |
| Net weight (kg) | 600 |
| Film (mm) | Max.250 |
