Pyramid Packaging Machine
Pyramid Packaging Machine
SilverSeal ref. SEV-225
The pyramid packaging machine draws 2100 W. It arrives wired for AC 220/50 110/60. Plan for a 1100×950×1900 mm footprint and 450 kg net on the floor.
- Voltage (V/Hz)
- AC 220/50 110/60
- Power (W)
- 2100
- Capacity
- 10-100
- Dimensions L×W×H (mm)
- 1100×950×1900
- Net weight (kg)
- 450
Overview
Z series Automatic Pyramidal Shape Bag Paste Packaging Machine is combined with a paste filling machine and sealing machine. The weighing, paste filling, packaging, and cutting processes are controlled by micro-computer. S o the packaging will be smooth. The shape of finished bag is pyramidal.
- Reliable performance
- Fl exible use
- Simple operation
- High efficiency
- PLC control
- Touch screen
- Suitable for multiple sizes
- Date code printer is optional Application:
Models in this series
3 sizes share this build. The table shows only what changes between them.
| Reference | Model | Capacity | Packing Object | Product Capacity (bags/min) |
|---|---|---|---|---|
| SEV-225 | SEV-225 | 10-100 | paste | 30-70 |
| SEV-230 | SEV-230 | 15-100 | granule | 35-70 |
| SEV-235 | SEV-235 | 10-100 | liquid | 25-60 |
Technical specifications
| Model | SEV-225 |
|---|---|
| Voltage (V/Hz) | AC 220/50 110/60 |
| Power (W) | 2100 |
| Capacity | 10-100 |
| Dimensions L×W×H (mm) | 1100×950×1900 |
| Net weight (kg) | 450 |
| Bag size (mm) | 50-80 |
| Packing Object | paste |
| Product Capacity (bags/min) | 30-70 |
