SEF-100
1 / 6
Piston Filler
Piston Filler
SilverSeal ref. SEF-140
The piston filler draws 20 W. It arrives wired for AC 220/50 or110/60. Set up with filling accuracy ≤1%, filling capacity 10-18, gas pressure 0.4-0.6.
- Voltage (V/Hz)
- AC 220/50 or110/60
- Power (W)
- 20
Overview
series Liquid Piston Filler is an automatic filling system, which uses compressed air as power and is made up of precision pneumatic components. It's suitable for liquid filling and floor type. Can set manual or automatic mode. The material contact part is 304 stainless steel. Part of the air cylinder is with brand Airtac.
Models in this series
4 sizes share this build. The table shows only what changes between them.
| Reference | Model | Filling Accuracy |
|---|---|---|
| SEF-140 | SEF-140 | ≤1% |
| SEF-145 | SEF-145 | ≤1% |
| SEF-150 | SEF-150 | ≤1% |
| SEF-155 | SEF-155 | ≤ 1% |
Technical specifications
| Model | SEF-140 |
|---|---|
| Voltage (V/Hz) | AC 220/50 or110/60 |
| Power (W) | 20 |
| Filling Accuracy | ≤1% |
| Filling Capacity (times/min) | 10-18 |
| Gas Pressure (Mpa) | 0.4-0.6 |
